| Model Number | PT-2720 |
| Range | 50mV/A | 5mV/A |
| Current range | DC: 0.4A~10AAC:0.4A~10Ap-p | DC: 10A~100AAC:10A~200Ap-p |
| Output signal error | 2% | 2% |
| Bandwidth(-3dB) | DC~300kHz |
| Load impedance | =1MO and =100pF |
| Impedance | 0.01O |
| Noise | 2mV |
| Rise time | 1.2µs |
| Operating voltage | Max.600Vrms |
| CMRR | Max.600Vrms |
| Battery | 9V (international delivery is forbidden,please buy it at local) |
| Low battery indicator | with green LED light when >6.5V |
| Overload indicator | Red LED light indicates the over measuring current, change the range |
| Mechanical Specifications |
| Operating temperature | 0~+50? |
| Storage temperature | ? |
| Temperature influence | Every 10?,<0.2% |
| Operating relative humidity | +10?~+30?:85±5% relative humidity(non-condensing )+40?~+50?:45±5%relative humidity(non-condensing ) |
| Operating height | 0~2000m |
| Max clam size | Diameter 11mm |
| Dimension | 231?36?67mm |
| Weight | 310g(not including battery) |
| Output | 2 meters of coaxial cable, with insulation BNC connector jack at the end |
